Dealer Drawings.
From luxurious custom Fleetwood Window & Door products, to fire-rated window systems from Fyre Tec, R+D Studio specializes with assisting dealers in creating project-specific shop drawings for all manufacturers. Our dealer shop drawings have proven to be beneficial in the preparation, installation, and overall longevity of all fenestration products.
Don’t See Your Brand? Contact Us!
Standard View Types.
-
Looking down at the finished floor, this view provides a layout of all fenestration products on the market.
When determining pocket dimensions, jamb locations, interlock alignments, and more - floor plan drawings are always a good start and final check.
-
Looking adjacent to the product’s exterior face, this view provides a sight-line representation of all fenestration products on the market.
Considering multiple layouts? Stile sizing, hardware location, vent insert locations, and more? Elevation drawings ensure proper frame dimensions produce the vertical alignments and look you envision.
-
Each detail is different depending on the scope of the product, situational conditions, and limitations.
Creating easy-to-understand details with overlaid manufacturer installation instructions provides contractors and architects with ready-to-use documents for in-the-field installation accuracy resulting in product longevity.
Pricing, Lead Times, + Revisions.
Floor Plan:
$185.00
*Per Line Item*
Elevation:
$185.00
*Per Line Item*
Product Details:
$180.00
*Per Product Type*
-
Estimated lead times on orders vary depending on size, demand, and current workload. Once given the go-ahead to proceed, orders consisting of less than 10 line items are typically produced within 5-10 business days.
R+D, however, is committed to a maximum production time of 20 business days on all orders - regardless of their size. If special accommodations due to time constraints are needed, shorter lead times may be feasible but may be subject to added charges depending on current workloads. For more information on the timing and cost of expedited production please contact: rykley.radstudio@gmail.com
-
All drafting orders placed with R+D Studio include a revision at no cost to the customer if submitted within one month of completion of said order. Revision times vary depending on the workload at the time of said revision request. If further revisions are needed, R+D may charge services at an hourly rate of $150/hour or submit a new contract(s) in regards to the added scope for approval.
